6 Error messages
110
Lenze · SM301 safety module · Parameter setting & configuration · DMS 2.3 EN · 11/2013 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
PROFIsafe has left data exchange [0x012f0025]
PROFIsafe - invalid data [0x012f0026]
F-parameter error [0x012f0027]
Discrepancy error or functional test SD-In1 [0x012f0031]
Module ID (decimal) Error ID (decimal)
303: SM301 safety module 37
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
A fault has occurred in the PROFIsafe data processing.
PROFIsafe has left data exchange.
• Check communication module, bus connection and
control program.
• Read out fault memory of control system.
Module ID (decimal) Error ID (decimal)
303: SM301 safety module 38
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
A fault has occurred in the PROFIsafe data processing.
PROFIsafe user data area has no valid data.
• Check communication module, bus connection and
control program.
• Read out fault memory of control system.
Module ID (decimal) Error ID (decimal)
303: SM301 safety module 39
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
A fault has occurred in the PROFIsafe parameterisation
phase. Wrong parameterisation of F-PLC.
• Check communication module, bus connection and
control program.
• Read out fault memory of control system.
Module ID (decimal) Error ID (decimal)
303: SM301 safety module 49
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Signal error at two-channel safe input SD-In1. • Check safe parameters for SD-In1.
• Check sensor at SD-In1.
