4 Safe parameter transfer
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
4 Safe parameter transfer
The functions for a safe parameter transfer are
available in the Safe transfer dialog box.
The Safe transfer dialog box is opened via the Safe
transfer button on the Safe configuration tab for the
SM301 safety module.
By clicking the More >> button in the Safe transfer
dialog box, the functions for password
management and general reset are displayed in
addition.
Clicking the button now labelled with << Reduce
hides these functions again.

Note!
To execute the functions for a safe parameter transfer, you have to enter a device
password!
When the memory module is used for the first time together with the safety module, the
required password file for the safe parameter transfer is not yet available in the memory
module and the error message "Reading of the password file failed" is displayed. In this
case a general reset of the device is required!
With a general reset, the safe parameter set is deleted in the memory module and in the
safety module and the required password file is created in the memory module. After
this, the safety module must be re-parameterised.  General reset of the device ( 69)
