Safe configuration
3.8
Safe output
38
Lenze · SM301 safety module · Parameter setting & configuration · DMS 2.3 EN · 11/2013 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Short overview of the "Safe output" parameter group:
SD-Out1 switching condition
Configuration of the switching conditions that are to be assigned to the safe output.
• Several switching conditions can be simultaneously assigned to the safe output.
• For each switching condition it can be individually set whether it is to be evaluated with a
positive or negative logic.
• In order to assign one or several conditions to the safe output, simply change the settings for
these conditions from "Not evaluated" to "Positive logic" or "Negative logic".
• The "SD-Out1" bit of the PROFIsafe output data is included in the evaluation via the selected
logic function. The evaluation for this bit can be deactivated via the parameters "S bus:
Configuration" and "S bus: Filter control data".
SD-Out1 logic function
Selection of the logic operation (OR or AND) for the switching conditions to be evaluated.
Parameter
Info
Lenze setting
SD-Out1 switching condition: STO active
Not evaluated
SD-Out1 switching condition: SS1 active
Not evaluated
SD-Out1 switching condition: SS2 active
Not evaluated
SD-Out1 switching condition: SLS1 active
Not evaluated
SD-Out1 switching condition: SLS2 active
*
Not evaluated
SD-Out1 switching condition: SLS3 active
*
Not evaluated
SD-Out1 switching condition: SLS4 active
*
Not evaluated
SD-Out1 switching condition: SDIpos active
**
Not evaluated
SD-Out1 switching condition: SDIneg active
**
Not evaluated
SD-Out1 switching condition: ES active
Not evaluated
SD-Out1 switching condition: SLI active
***
Not evaluated
SD-Out1 switching condition: OMS
Not evaluated
SD-Out1 switching condition: SOS monitored
Not evaluated
SD-Out1 switching condition: SLS1 monitored
Not evaluated
SD-Out1 switching condition: SLS2 monitored
*
Not evaluated
SD-Out1 switching condition: SLS3 monitored
*
Not evaluated
SD-Out1 switching condition: SLS4 monitored
*
Not evaluated
SD-Out1 switching condition: SDIpos monitored
**
Not evaluated
SD-Out1 switching condition: SDIneg monitored
**
Not evaluated
SD-Out1 switching condition: SSE active
Not evaluated
SD-Out1 switching condition: SD-In1 active
Not evaluated
SD-Out1 switching condition: SD-In2 active
Not evaluated
SD-Out1 switching condition: SD-In3 active
Not evaluated
SD-Out1 switching condition: SD-In4 active
Not evaluated
SD-Out1 switching condition: OMS active
Not evaluated
SD-Out1 switching condition: Error active
Not evaluated
SD-Out1 logic function
OR
* From SM301 V1.1 ** From SM301 V1.3 *** From SM301 V1.4
