6 Error messages
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Reserved (PROFIsafe standard) [0x012f004a]
Error - SD-Inx / CLx [0x012f0051]
Error - SD-Inx / CLx [0x012f0052]
Short circuit - SD-Out [0x012f0059]
Error - internal disconnecting path [0x012f005d]
Module ID (decimal) Error ID (decimal)
303: SM301 safety module 74
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
-- --
Module ID (decimal) Error ID (decimal)
303: SM301 safety module 81
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Internal error at a safe input (hardware error). Replace safety module.
Module ID (decimal) Error ID (decimal)
303: SM301 safety module 82
Response (Lenze setting printed in bold)
 None  System error  Error  Fault  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Error at an SD-Inx input or the CLx clock outputs.
Only valid for the SM300 safety module!
Check wiring at the SM300 safety module.
Module ID (decimal) Error ID (decimal)
303: SM301 safety module 89
Response (Lenze setting printed in bold)
 None  System error  Error  Fault  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Error at output SD-Out.
Only valid for the SM300 safety module!
Check wiring at the SM300 safety module.
Module ID (decimal) Error ID (decimal)
303: SM301 safety module 93
Response (Lenze setting printed in bold)
 None  System error  Error  Fault  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Internal error of safe switch-off logic. Replace safety module. Contact Lenze.
