6 Error messages
108
Lenze · SM301 safety module · Parameter setting & configuration · DMS 2.3 EN · 11/2013 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Internal error, STO activated [0x012f0001]
Internal error, SS1 activated [0x012f0002]
Internal error, SS2 activated [0x012f0003]
Communication error - standard device [0x012f0010]
Synchronisation error - standard device [0x012f0011]
Module ID (decimal) Error ID (decimal)
303: SM301 safety module 1
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Internal error, STO activated. Replace safety module. Contact Lenze.
Module ID (decimal) Error ID (decimal)
303: SM301 safety module 2
Response (Lenze setting printed in bold)
 None  System error  Error  Fault  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Internal error, SS1 activated Replace safety module. Contact Lenze.
Module ID (decimal) Error ID (decimal)
303: SM301 safety module 3
Response (Lenze setting printed in bold)
 None  System error  Error  Fault  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Internal error, SS2 activated Replace safety module. Contact Lenze.
Module ID (decimal) Error ID (decimal)
303: SM301 safety module 16
Response (Lenze setting printed in bold)
 None  System error  Error  Fault  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Communication between the standard device and the
safety module has been interrupted. Standard device has
been switched off.
Ensure operation in the specified voltage limits.
Module ID (decimal) Error ID (decimal)
303: SM301 safety module 17
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Faulty synchronisation with standard device. Please contact Lenze.
