3 Safe configuration
3.6 General parameters
30
Lenze · SM301 safety module · Parameter setting & configuration · DMS 2.3 EN · 11/2013 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
3.6.1 Setting of the safety address
The safety address can be set via the DIP switch of the safety module or via the "safety address"
parameter ( C15111 ).
Setting via DIP switch
• The DIP switch serves to set addresses in the range of 0 ... 1023:
• Changes of the safety address via the DIP switch are only activated when the 24 V supply is
switched on.
• C15101 displays the safety address set with the DIP switch.
Setting via parameter setting
• Via the parameter "safety address" ( C15111 ) addresses in the range of 0 ... 65534 can be set.
Effective safety address
The effective safety address is the result of the setting via DIP switch or parameter setting.
• The effective safety address must match the module ID assigned in the safe parameter set.
• If "PROFIsafe" has been selected as safety bus, the effective safety address is accepted
simultaneously as the PROFIsafe target address. This address must match the corresponding
configuration of the safety PLC.

Tip!
C15112 displays the effective safety address.

Note!
• The DIP switch in the left housing side of the safety module can only be set if the
safety module is not plugged into the controller.
• The setting of the safety address via parameter setting is only possible if the safety
address "0" is set with the DIP switch. Otherwise the safety address set via the DIP
switch is used.
• The safety address "0" is not permissible!
DIP switch Labelling
1 2 3 4 5 6 7 8 9 0
Value of the address bit 1 2 4 8 16 32 64 128 256 512
