5 Parameter reference
5.1 Parameter list | C15000
72
Lenze · SM301 safety module · Parameter setting & configuration · DMS 2.3 EN · 11/2013 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C15000
Parameter | Name:
C15000 | Status of safety functions
Data type: BITFIELD_32
Index: 9575
d
= 2567
h
Bit-coded status word of the safety functions
Display range
0x00000000
0xFFFFFFFF
Value is bit-coded: Info
Bit 0 STO is active  Safe torque off
Bit 1 SS1 active  Safe stop 1
Bit 2 SS2 active  Safe stop 2
Bit 3 SLS1 active  Safely limited speed 1
Bit 4 SLS2 active  Safely limited speed 2 (from V1.1)
Bit 5 SLS3 active  Safely limited speed 3 (from V1.1)
Bit 6 SLS4 active  Safely limited speed 4 (from V1.1)
Bit 7 SDIpos active  Safe positive direction (from V1.3)
Bit 8 SDIneg active  Safe negative direction (from V1.3)
Bit 9 ES active  Safe enable switch
Bit 10 SLI active  Safely limited increment (from V1.4)
Bit 11 OMS  Safe operation mode selector
Bit 12 Reserved
Bit 13 Reserved
Bit 14 Reserved
Bit 15 Reserved
Bit 16 SOS monitored
Safe operating stop is monitored.
Bit 17 SLS1 monitored Safely limited speed 1 is monitored.
Bit 18 SLS2 monitored Safely limited speed 2 is monitored (from V1.1)
Bit 19 SLS3 monitored Safely limited speed 3 is monitored (from V1.1)
Bit 20 SLS4 monitored Safely limited speed 4 is monitored (from V1.1)
Bit 21 SDIpos monitored Safe positive direction is monitored (from V1.3)
Bit 22 SDIneg monitored Safe negative direction is monitored (from V1.3)
Bit 23 SSE active  Emergency stop function
Bit 24 SD-In1 active  Safe inputs
Bit 25 SD-In2 active  Safe inputs
Bit 26 SD-In3 active  Safe inputs
Bit 27 SD-In4 active  Safe inputs
Bit 28 Reserved
Bit 29 OMS active
 Safe operation mode selector (from V1.1)
Bit 30 Reserved
Bit 31 Fault active
 Read access  Write access  CINH  PLC-STOP  No transfer
