5 Parameter reference
5.1 Parameter list | C15034
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C15034
C15035
C15036
Parameter | Name:
C15034 | SD-In input delay
Data type: UNSIGNED_8
Index: 9541
d
= 2545
h
Time between the recognition of the signal change and the effective evaluation of an input signal. As a result,
multiple and short signal changes due to contact bounce of the components are not taken into account.
 Safe inputs
Setting range (min. value | unit | max. value)
0 ms 100
Subcodes Lenze setting Info
C15034/1 0 ms SD-In1 input delay
C15034/2 0 ms SD-In2 input delay
C15034/3 0 ms SD-In3 input delay
C15034/4 0 ms SD-In4 input delay
 Read access  Write access  CINH  PLC-STOP  No transfer Scaling factor: 1
Parameter | Name:
C15035 | CAS: Cascading
Data type: UNSIGNED_8
Index: 9540
d
= 2544
h
From V1.1
Activation of the cascading function.
Use of SD-In4 as cascading input and SD-Out1 as cascading output.
 Safe cascading
Selection list (Lenze setting printed in bold)
0 No cascading
4 Cascading with SD-In4
 Read access  Write access  CINH  PLC-STOP  No transfer Scaling factor: 1
Parameter | Name:
C15036 | CAS: Stop delay
Data type: UNSIGNED_16
Index: 9539
d
= 2543
h
From V1.1
Delay between setting and receiving the stop signal via cascading.
 Safe cascading
Display range (min. value | unit | max. value)
0 ms 65535
 Read access  Write access  CINH  PLC-STOP  No transfer Scaling factor: 1
