Introduction
Legend
The welded metal cab features European styling and a
modular design, allowing for a relatively quick, simple
exchange of the entire cab and/or component parts. The
cab is bolted to the cab mount, which in turn is bolted
to the frame.
The operator’s cab is a protective structure. The cab
itself contains roll-over protective and falling object pro-
tective structures (ROPS/FOPS) for the operator.
DO NOT weld, grind, drill, repair or modify the cab in
any way. Any modification or damage to cab structural
components requires cab replacement. The lives of the
operator and others are potentially at stake.
To help ensure optimum safety, protection and perfor-
mance, replace the cab if it is damaged. Refer to the
SKY TRAK Model 3606 Parts Manual for ordering infor-
mation.
The cab contains the seat, operating controls, numer-
ous panels, steering and brake components, and more.
Covers and mirrors on the vehicle exist for safety, pro-
tection and appearance. They are relatively simple to
remove and replace.
WARNING: The protection offered by this
ROPS/FOPS will be impaired if subjected to
any modification or structural damage at which
time replacement is necessary. ROPS/FOPS
must be properly installed using fasteners of
correct size and grade, torqued to their speci-
fied value.
Model 3606 • Origin 10/99
1. Operator’s Protective Structure
ROPS/FOPS
2. Headliner
3. Cab rear panel
4. Button-head capscrew, 5/16-18 x 1
5. Flat plastic washer, 5/16"
6. Retaining nut, 5/16-18
7. Hex-head capscrew, 5/16-18 x 1
8. Lock washer, 5/16"
9. Rebound washer
10. Cab panel, rear LH
11. Flat washer, 5/16"
12. Hex-lock elastic nut, 3/4-10
13. Button-head capscrew, 1/4-20 x 3/4
14. Owners/Operators Manual holder
15. Flat washer, 1/4"
16. Hex-lock elastic nut, 1/4-20
17. Floor mat
18. Self-drilling screw, #12-14 x 1
19. Cab panel, front LH
20. Cab isolator
21. Rebound washer
22. Hex-head capscrew, 3/4-10 x 3-3/4",
Grade 8
23. Lock washer, 3/4"
24. Cab panel, front
25. Window spacer
26. Window edge seal bulb
27. *Right side window
28. Window clip, w/offset
29. Screw
30. Window clip
31. Spray adhesive, 10 ounce spray can
(for item 17)
32. *Steel mesh window (option),
glued in
