Section 10
10-18 Model 3606 • Origin 10/99
10.4.2 Cab Harness, S/N 8250-9398
Use this chart for vehicles with S/N 8250-9398.
WIRE No. COLOR GAUGE FUNCTION
2 BLK 16 Generic Ground
2B BLK 16 Hourmeter to Ground Splice 40
2C BLK 16 Shift Control Relays to Cab Ground Stud
2D BLK 16 Fuel Level Sender to Ground Splice 50
2E BLK 14 Joystick Logic Board to Ground Splice 40
2F BLK 16 Steer Select Lamp (Terminal 7) to Ground Splice 40
2G BLK 16 Display Panel to Ground Splice 40
2H BLK 16 Display Panel to Ground Splice 40
2J BLK 16 Boom Function Solenoids to Ground Splice 35
2K BLK 10 Ground Splice 45 to Ground Splice 50
2S BLK 16 Seat Belt Switch to Ground Splice 50
2T BLK 16 Backup Alarm to Ground Splice 35
2U BLK 16 Ground Splice 40 to Park Brake Lamp (Terminal 7)
2V BLK 12 Ground Splice 40 to Cab Ground Stud
2Y BLK 10 Ground Splice 35 to Ground Splice 50
2AA BLK 10 Ground Splice 50 to Cab Ground Stud
2BB BLK 10 Ground Jumper for Neutral Relay
2CC BLK 16 Ground Splice 40 to Stabil-TRAK Relays
2EE BLK 16 Ground Splice 35 to Stabil-TRAK Solenoid #5
2FF BLK 16 Ground Splice 35 to Stabil-TRAK Solenoid #4
2GG BLK 16 Ground Splice 35 to Stabil-TRAK Solenoid #3
2HH BLK 16 Ground Splice 35 to Stabil-TRAK Solenoid #2
2JJ BLK 16 Ground Splice 35 to Stabil-TRAK Solenoid #1
2KK BLK 16 Ground Splice 35 to Boom Proximity Switch
2LL BLK 16 Ground Splice 40 to Relay 1
2MM BLK 16 Ground Splice 40 to Neutral Relay
3 RED 10 Starter (+) Power to (+) Grid (fuse panel bus)
4 YEL/BLU 16 Neutral Relay to Starter Relay
5 YEL/RED 14 Ignition Switch (Terminal 4) to 7.5-amp Fuses
6 ORN 10 Ignition Switch to 40-amp Main Fuse
7 BRN 10 Ignition Switch to (+) Grid (fuse panel bus)
8 PNK 16 7.5-amp Fuse to Park Brake Switch (Terminal 5)
9 RED/WHT 16 Park Brake Switch (Terminal 6) to Neutral Relay
10 PNK/GRN 16 Alternator Indicator Terminal to CUMMINS Indicator Logic
10A PNK/GRN 16 Alternator Indicator Terminal to PERKINS Indicator Logic
11 PUR/WHT 16 Oil Pressure Logic to Oil Pressure Switch
12 RED/BLU 16 Engine Coolant Temperature Logic to Engine Coolant Temperature Switch
14 WHT/BRN 16 Hydraulic Oil Temperature Logic to Hydraulic Oil Temperature Switch
15 DK GRN 16 Ignition Switch to 7.5-amp Fuse for Shift Control
16 WHT/ORN 16 7.5-amp Fuse to Park Brake Switch (Terminal 2)
17 PNK/WHT 16 7.5-amp Fuse to Steer Select Switch (Terminal 2)
18 GRY/GRN 16 Steer Select Switch (Terminal 1) to Steer Select Solenoid (C)
18A GRY/GRN 16 Steer Select Switch (Terminal 1) to Steer Select Logic
19 YEL/BLK 16 Steer Select Switch (Terminal 3) to Steer Select Solenoid (Terminal 4)
19A YEL/BLK 16 Steer Select Switch (Terminal 3) to Steer Select Logic
20 BRN/YEL 14 7.5-amp Fuse to Shift Control Switch (Terminal 8)
21 YEL/BLU 16 Shift Control Relay to Reverse Clutch Solenoid
22 DK GRN/WHT 16 Splice 20 to Backup Alarm
23 RED/GRY 16 Shift Control Relay to Forward Clutch Solenoid
24 ORN/BLU 16 Transmission Shuttle Clutch Solenoid to Splice 8
24A ORN/BLU 16 Splice 80 to Transmission Logic
25 LT BLU 16 Transmission Shift Control Switch to First Gear Clutch Solenoid
