General Information, Specifications, and Maintenance
2-7
C. Cylinder Times (with no load, at full throttle)
Function Approximate Times, in seconds
Boom extend 12.00
Boom retract 7.00
Boom lift retracted 12.75
Boom lower retracted 10.75
Fork tilt up 4.20
Fork tilt down 3.75
Frame tilt left to right
with boom down
8.50
Frame tilt left to right with boom above 40 ° and emergency
brake engaged 24.0 to 30.0
Frame tilt right to left
with boom down
13.50
Frame tilt right to left with boom above 40 ° and emergency
brake engaged 24.0 to 30.0
D. Draw Bar Pull
Per SAE drawbar test, 200 ft (61 m) track
4-SPEED 3-SPEED
Peak drawbar
in 1st gear
at converter stall
(no load)
15,000 lb 13,250 lb
(6.810,0 kg), slip (6.015,5 kg), no slip
Peak drawbar
in 1st gear
at converter stall
(rated load)
16,750 lb 13,250 lb
(7.604,5 kg), no slip (6.015,5 kg), no slip
E. Engine Performance
Note: Engine manufacturer’s maximum “high idle” setting
is lockwired and sealed. DO NOT disturb this setting.
F. Fuel Consumption
Average, depending on load/duty:
2 gal/hr (1,67 Imp gal/hr, or 7,57 l/hr)
G. Steering Wheel
Maximum number of turns, lock to lock
3.80 turns
Minimum number of turns, lock to lock
3.20 turns
H. Breakout Force
Utility bucket (calculated at -24 ° lip angle, max moment)
15,100 lb (6.855,4 kg).
2.4.3 Weights
A. Basic Vehicle
Curb Weight 20,195 lbs (9.160 kg)
Operating Load 6,600 lbs (3.000 kg)
B. Working Weight
Machine working weight is figured with 48" carriage, two
48" pallet forks, 25%-full fuel tank, and standard bias ply
tires (no hydrofill):
Front Axle Rear Axle TOTAL
Open Cab 8,390 lb 12,540 lb 20,930 lb
(3,8 kg) (5,6 kg) (950 kg)
Closed Cab N/A N/A N/A
C. Attachments
Std 48" carriage with shaft ....................... 456 lb (205 kg)
Std 60" carriage with shaft .................... 526 lb (236,7 kg)
Std 72" carriage with shaft .................... 677 lb (304,6 kg)
48" side tilt carriage
with shaft and cylinder.............................. 640 lb (288 kg)
60" side tilt carriage
with shaft and cylinder.............................. 700 lb (315 kg)
72" side tilt carriage
with shaft & cylinder .............................. 770 lb (346,5 kg)
52" swing carriage
with shaft & cylinders ............................ 950 lb (427,5 kg)
72" swing carriage
with shaft and cylinder...................... 1,135 lb (510,75 kg)
Bucket, 1.125 yd
3
(0,855 m
3
) ................... 760 lb (342 kg)
Broom, 8 foot (2,44 m) .......................... 1,100 lb (495 kg)
Pallet forks, 2.25 x 4 x 48 (5,7 x 10 x 122 cm),
quantity: 2 ............................................. 312 lb (140,4 kg)
Low idle setting for all engines = 1050 +/- 50 RPM
Engine Model
Displace-
ment
High Idle
Horse-
power
Peak
Torque
Perkins
Turbo 1004.4T 243 CID 2600 +/-
100 108 HP @
2400 rpm 277 lb/ft
@ 1600
rpm
Perkins
Natural/
EPA 1004.42 258 CID 2600 +/-
100 86 HP
@ 2400
rpm 221 lb/ft
@ 1600
rpm
Cummins
Turbo 4BT3.9 239 CID 2700 +/-
100 110 HP @
2500 rpm 293 lb/ft
@ 1500
rpm
Model 3606 • Origin 10/99
