Hydraulic System
9-53
Attachment Tilt/Slave Cylinder Legend
1. Hose, 1/2” I.D. x 33-1/2”
2. Hose, 1/2” I.D. x 16”
3. Hose, 1/2” I.D. x 39”
4. Bulkhead Fitting Support
5. Twin Hose Clamp Set, 0.78” I.D.
6. Twin Welding Plate
7. Hex-head Capscrew, 5/16-18 x 1-1/2”
8. Plain Washer, 1/4”
9. Hex-lock Nut, 1/4-20
10. Hex-lock Nut, 5/16-18
11. Cover Plate
12. 90° Bulkhead Elbow, SAE 10 - O-Ring Face Seal
13. 45° Bulkhead Elbow, SAE 10 - O-Ring Face Seal
14. Union Connector, SAE 10 - O-Ring Face Seal
15. Attachment Tilt Retract Tube Assembly
16. Attachment Tilt Extend Tube Assembly
17. Tube Assembly
18. Tube Assembly
19. Grade 5 Fully-threaded Tap Bolt, 5/16-18 x 2-1/2”
20. Bulkhead Nut, SAE 10 - O-Ring Face Seal
21. 90° Swivel Elbow, SAE 8 - O-Ring Face Seal
22. Hose, 1/2” I.D. x 321”
23. Twin Hose Clamp Set, 0.62” I.D.
24. Lockwasher, 5/16”
25. Cover Plate
26. Twin Welding Plate
27. Male Run Tee, SAE 8 - ORFS Tube End x Str. Thd. O-Ring
28. Cap, SAE 8 - O-Ring Face Seal
29. 90° Elbow, SAE 8 - Str. Thd. ORB x O-Ring Face Seal
Model 3606 • Origin 10/99
