Section 10
10-20 Model 3606 • Origin 10/99
76 PNK/BLU 16 4TH Gear (optional--if equipped) Splice to Transmission Relay 2 (Terminal 85)
77 PUR 10 Ignition Switch (Terminal 5) to 15-amp Fuse
92 TAN/PUR 16 Splice 200 to Lamp Fuse
93 LT BLU/PUR 16 Splice 110 to Cummins Cold Start Switch (optional)
137 LT BLU/ORN 16 Attachment Tilt Switch (Terminal 2) to +12V Logic
138 GRN/BLU 16 Attachment Tilt Switch (Terminal 3) to Signal
139 ORN/GRY 16 Attachment Tilt Switch (Terminal 8) to Splice 200
WIRE No. COLOR GAUGE FUNCTION
