Section 8B
8B-2
Introduction
Legend
DISCLAIMER AND SCOPE
These instructions are written for worldwide use. In
territories where legal requirements govern engine
smoke emission, noise, safety factors, etc., apply all
instructions, data and dimensions provided herein in
such a way that after maintenance, service and repair
of the engine, engine operation does not violate local
regulations.
IMPORTANT: These instructions cover only the routine
maintenance, removal, installation and troubleshooting
of the engine. Refer to the local Cummins Engine Dis-
tributor and the applicable Cummins engine service
manual for assistance with comprehensive engine diag-
nosis, repair and component replacement.
A gradual running in (break in) of a new engine is not
necessary. Full load can be applied to a new engine as
soon as the engine is put into service and the coolant
temperature is at least 140° F (60°C). Extended light-
load operation during the early life of the engine is not
recommended. DO NOT run the engine at high, no-
load speeds. DO NOT apply an overload to the engine.
Throughout this section, the left or right side of the
engine is as viewed from the flywheel end.
Model 3606 • Origin 10/99
1. Cummins 4BT3.9 Turbo Engine
2. Fan Belt
3. Suction Fan, 18"
4. Hex-head Capscrew,
M10-1,5 x 90 mm
5. Lockwasher, M10
6. Alternator Fan
7. Alternator, 65 Amp
8. Flat-face Straight Connector,
#10 ORB x #12
9. Flat-face Elbow Swivel, #12
10. Remote Oil Filter Hose Assembly
11. Tie Wrap
12. Hex-lock Elastic Nut, 7/16-14
13. Rebound Washer, 7/16"
14. Lockwasher, M12
15. Hex-head Capscrew,
M12-1,75 x 30 mm PC 8,8
16. Rear Left-side Engine Mount
17. Engine Mount
18. Hex-head Capscrew,
3/8-16 x 1-1/4 Grade 5
19. Narrow Flat Washer, 3/8"
20. Hex-lock Elastic Nut, 3/8-16
21. Narrow Flat Washer, 7/16"
22. Hex-head Capscrew,
7/16-14 x 3-1/4" Grade 8
23. Hex-head Capscrew,
5/8-11 x 4" Grade 8
24. Narrow Flat Washer, 5/8"
25. Hex-head Capscrew,
3/8-16 x 1-1/2 Grade 5
26. Engine Mount
27. Front Left-side Engine Mount
28. Hex-head Capscrew,
M12-1,75 x 40 mm PC 8,8
29. Rebound Washer, 5/8"
30. Hex-lock Elastic Nut, 5/8-11
31. Front Right-side Engine Mount
32. Rear Right-side Engine Mount
33. Engine Oil Filter
34. Flat-face Elbow, 90 ° , #12 ORB x
#12
35. Oil Filter Bracket
36. Lockwasher, 1/4"
37. Hex-head Capscrew,
1/4-20 x 5/8"
38. Hex-head Capscrew,
M12-1,75 x 25 mm
39. Starter
40. Starter Relay Mount
41. Hex-lock Elastic Nut, 1/4-20
42. Starter Relay
43. Hex-head Capscrew,
1/4-20 x 3/4"
