Page 344
Section 10
10-26
Model 3606 • Origin 10/99
10.4.3 Cab Harness, S/N 9399 and After
Use this chart for vehicles with S/N 9399 and after.
WIRE No.
COLOR
GAUGE
FUNCTION
2 BLK 16
Generic
Ground
2B
BLK
16
Hourmeter to Ground Splice 40
2C
BLK
16
Shift Control Relays to Cab Ground Stud
2D
BLK
16
Fuel Level Sender to Ground Splice 50
2E
BLK
14
Joystick Logic Board to Ground Splice 40
2F
BLK
16
Steer Select Lamp (Terminal 7) to Ground Splice 40
2G
BLK
16
Display Panel to Ground Splice 40
2H
BLK
16
Display Panel to Ground Splice 40
2J
BLK
16
Boom Function Solenoids to Ground Splice 35
2K
BLK
10
Ground Splice 45 to Ground Splice 50
2S
BLK
16
Seat Belt Switch to Ground Splice 50
2T
BLK
16
Backup Alarm to Ground Splice 35
2U
BLK
16
Ground Splice 40 to Park Brake Lamp (Terminal 7)
2V
BLK
12
Ground Splice 40 to Cab Ground Stud
2Y
BLK
10
Ground Splice 35 to Ground Splice 50
2AA
BLK
10
Ground Splice 50 to Cab Ground Stud
2BB
BLK
10
Ground Jumper for Neutral Relay
2CC
BLK
16
Ground Splice 40 to Stabil-TRAK Relays
2EE
BLK
16
Ground Splice 35 to Stabil-TRAK Solenoid #5
2FF
BLK
16
Ground Splice 35 to Stabil-TRAK Solenoid #4
2GG
BLK
16
Ground Splice 35 to Stabil-TRAK Solenoid #3
2HH
BLK
16
Ground Splice 35 to Stabil-TRAK Solenoid #2
2JJ
BLK
16
Ground Splice 35 to Stabil-TRAK Solenoid #1
2KK
BLK
16
Ground Splice 35 to Boom Proximity Switch
2LL
BLK
16
Ground Splice 40 to Relay 1
2MM
BLK
16
Ground Splice 40 to Neutral Relay
3
RED
10
Starter (+) Power to (+) Grid (fuse panel bus)
4
YEL/BLU
16
Neutral Relay (Terminal 87) to Starter Relay (coil positive terminal)
5
YEL/RED
14
Ignition Switch (Terminal 2) to Switched Grid (fuse panel bus)
6
ORN
10
Ignition Switch to 30-amp Main Fuse
7
BRN
10
Ignition Switch (Terminal 4) to (+) Grid (fuse panel bus)
7A
BRN/WHT
10
Closed Cab Relay (Terminal 85) to Splice 65
8
PNK
16
7.5-amp Fuse to Park Brake Switch (Terminal 5)
9
RED/WHT
16
Park Brake Switch (Terminal 6) to Neutral Relay (Terminal 30)
10
PNK/GRN
16
Alternator Indicator Terminal to CUMMINS Input (10GY/D)
10A
PNK/GRN
16
Alternator Indicator Terminal to PERKINS Input (10GY/F)
11
PUR/WHT
16
Oil Pressure Input (Terminal 10/C) to Oil Pressure Switch (Terminal A)
12
RED/BLU
16
Water Temperature Logic (10/B) to Water Temperature Switch
14
WHT/BRN
16
Hydraulic Oil Temperature Logic (10GY/A) to Hydraulic Oil Temperature Switch
15
DK GRN
16
Ignition Switch (Terminal 3) to 7.5-amp Fuse
16
WHT/ORN
16
7.5-amp Fuse to Park Brake Switch (Terminal 2)
17
PNK/WHT
16
7.5-amp Fuse to Steer Select Switch (Terminal 2)
18
GRY/GRN
16
Steer Select Switch (Terminal 1) to Steer Select Solenoid (Terminal 4)
19
YEL/BLK
16
Steer Select Switch (Terminal 3) to Steer Select Solenoid (Terminal 4)
19A
YEL/BLK
16
Steer Select Switch (Terminal 3) to Steer Select Logic (Terminal 6/E)
20
BRN/YEL
14
7.5-amp Fuse to Shift Control Switch (Terminal 8)
21
YEL/BLU
16
Reverse Relay (Terminal 87) to Reverse Clutch Solenoid
22
DK GRN/WHT
16
Splice 20 to Reverse Alarm
23
RED/GRY
16
Forward Relay (Terminal 87) to Forward Clutch Solenoid
24
ORN/BLU
16
Transmission Relay 3 (Terminal 87) to Shuttle Clutch Solenoid
24A
ORN/BLU
16
Splice 80 to Fourth Gear (optional--if equipped) Input (Terminal 6/C)
25
LT BLU
16
Transmission Shift Control Switch (through Splice 60) to 1st Clutch Solenoid
