Hydraulic System
9-57
Valve Plate Assembly Legend
(without auxiliary hydraulics)
1. Pilot Select Manifold
2. Main Control Valve
3. Shuttle Valve
4. Spacer
5. Main Valve Bracket
6. Hose, 3/8" I.D. x 18"
7. Hose, 3/8" I.D. x 19.3"
8. Hose, 3/8" I.D. x 20"
9. Carriage Bolt, 3/8-16 x 2-1/4"
10. Long Connector, SAE 8 - Str. Thd. ORB x O-Ring Face Seal
11. Branch Tee, SAE 8 - Str. Thd. ORB x O-Ring Face Seal
12. 90° Elbow, SAE 6 - Str. Thd. ORB x O-Ring Face Seal
13. Branch Tee, SAE 6 - Str. Thd. ORB x O-Ring Face Seal
14. Swivel Run Tee, SAE 6 - O-Ring Face Seal
15. Cap, SAE 6 - O-Ring Face Seal
16. Connector, SAE 6 - Str. Thd. ORB x O-Ring Face Seal
17. Male Run Tee, SAE 6 - ORFS Tube End x Str. Thd. O-Ring
18. Long Connector, SAE 6 - Str. Thd. ORB x O-Ring Face Seal
19. 90° Swivel Elbow, SAE 6 - O-Ring Face Seal
20. Connector, SAE 6-8 - Str. Thd. ORB x O-Ring Face Seal
21. Swivel Run Tee, SAE 8 - O-Ring Face Seal
22. Connector, SAE 8 - Str. Thd. ORB x O-Ring Face Seal
23. Connector, SAE 12 - Str. Thd. ORB x O-Ring Face Seal
24. 90° Elbow, SAE 12 - Str. Thd. ORB x O-Ring Face Seal
25. Connector, SAE 16-12 - Str. Thd. ORB x O-Ring Face Seal
26. Swivel Branch Tee, SAE 16 - O-Ring Face Seal
27. 90° Swivel Elbow, SAE 8 - O-Ring Face Seal
28. Washer, Plain 1/2"
29. Lockwasher, 1/4"
30. Lockwasher, 1/2"
31. Hex-head Capscrew, 1/4-20 x 2-1/2" Gr. 5
32. Hex-head Capscrew, 1/2-13 x 3-1/2" Gr. 5
33. Hex-head Capscrew, 1/2-13 x 1" Gr. 5
34. Hex Nut, 1/4-20
35. Hex Nut, 1/2-13
36. Lockwasher, 3/8"
37. Hex Nut, 3/8-16
38. Dust Plug
39. Diagnostic Nipple
40. Tube Nut, SAE 16 - O-Ring Face Seal
41. Reducer, SAE 16 - O-Ring Face Seal x SAE 8 - O-Ring
Face Seal
42. 90° Swivel Elbow, SAE 6 - Str. Thd. ORB x O-Ring Face
Seal
43. Hex-head Plug, SAE 6 - Male Str. Thd. O-Ring
44. Shut-off Plug
Model 3606 • Origin 10/99
