SkyTrak 3606 Service Manual - Manual (Page 243)

Hydraulic System
9-49
Figure 9– 38. Attachment tilt/slave cylinder schematic.
3700
PSI
3700
PSI
BYPASS TO RESERVOIR
A B a
LOAD
SENSE OUT
INLET
15
GPM
MAX
2
1
7 8
SLAVE CYLINDERS
4000
PSI
4000
PSI
5 PSI
SPOOL
3500
PSI
65
PSI
250
PSI
INLET
25
PSI
3.0 IN
0.5 PSI
4
RELIEF
VALVE
2500 RPM
32.5 GPM
BACK
1 3
FWD
T P
2500
PSI
550
PSI
PP PPG PB
.090
DIA
PSG PS
P
PBG
T
650
PSI
4
3
PILOT SELECT MANIFOLD
JOYSTICK
AUXILIARY FUNCTION MANIFOLD
MAIN CONTROL VALVE ASSEMBLY
SHUTTLE IN
UNLOADER VALVE
b
ATTACHMENT TILT
ATTACHMENT
TILT AUX 1
15 16
ATTACHMENT TILT
CYLINDER
RETURN TO RESERVOIR
MS0060
Model 3606 • Origin 10/99
