Section 2
2-38
Figure 2–68. Vehicles with serial number 8249 and before
use the fuse and relay panel shown here.
Figure 2–69. Vehicles stamped with serial number 8250
through 9398 use the fuse and relay panel shown here.
Vehicles Stamped with S/N 8249 and Before
Neutral Relay/Starter
Fuel Shut-off
Display Panel
Main Fuse
Switch Lamps
Stabil-TRAK Solenoid
Stabilizer Lock Relay
Hourmeter
Perkins Cold
Start (optional)
Neutral
Sense
Logic
Panel
Trans-
mission
Relay
Horn
Steer
Solenoids
Park Brake
Sense
Trans-
mission
Solenoids
Neutral Relay
Forward Relay
Reverse Relay
Trans. Relay 1
Trans. Relay 2
Trans. Relay 3
Boom Switch Relay
Stabilizer Lock Relay
OS1113
15
30
7.5
7.5 7.5 7.5 7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5 7.5
7.5
7.5
OS1770
*Cold Start
Main
Hourmeter
Fuel Shut-Off
Trans. Relay
Park Brake
Sense Relay
Transmission
Solenoids
Vehicles Stamped with S/N 8250 through 9398
Neutral
Relay/Starter
Display
Panel
Logic
Panel Neutral
Sense
*Switch Lamps
Horn
*Aux.
Detent
Mode
Steer
Solenoids
Stabil-TRAK
Solenoid
Stabilizer Lock Relay
Reverse Relay
Forward Relay
Stabilizer Lock
Relay
Boom Switch
Relay
*Optional
Neutral Relay
Trans. Relay #3
Trans. Relay #2
Trans. Relay #1
Model 3606 • Origin 10/99
