AT-S25 Management Software User’s Guide
65
Link The status of the link between the port and the end
node connected to the port.
Possible settings for this parameter are:
• Up - indicates that a valid link exists between the port
and the end node.
• Down - indicates that the port and the end node have
not established a valid link.
Speed The operating speed of the port.
Possible settings for this parameter are:
• 10 Mbps = 10 MB
• 100 Mbps = 100 MB
• 1000 Mbps = 1 GB (AT-8324 uplink only)
Duplex
The duplex mode of the port.
Possible settings for this parameter are:
• Half-duplex
• Full-duplex
PVID The port VLAN identifier currently assigned to the port.
FlowCtrl The flow control setting for the port.
Possible settings for this parameter are:
• Enable
• Disable
STP_State The current operating status of the port.
Possible settings for this parameter are:
• Disable
• Blocking
• Listening
• Learning
• Forwarding
PARAMETER DESCRIPTION
