Section III: Web Browser Management
196
Configuring an IP Address and Switch Name
Note
For guidelines on when to assign an IP address, subnet address, and
gateway address to an AT-8316F or an AT-8324 Switch, refer to
When Does a Switch Need an IP Address? on page 42.
To set the basic parameters for an AT-8316F or an AT-8324 Switch,
perform the following procedure:
1. From the Home Page, select Configuration.
The Configuration window is displayed with the System menu
option selected by default.
2. If the System menu option is not selected, select it and then select the
General tab.
The General window in Figure 70 is displayed.
Figure 70 Configuration - General Window
