Section II: Local and Telnet Mangement

The master switch is the switch assigned the Stack ID value of 1.
For information on Stack ID switch settings, refer to the AT-
8316F/MT, AT-8316F/VF, AT-8316F/SC, and AT-8324 Installation
Guide.

Note
Do not connect the terminal to the RS232 port on a slave switch. To
start a local management interface on a stack, you must connect the
terminal to the RS232 port on the master switch.

2. Connect the other end of the cable to an RS-232 port on a terminal or

PC with a terminal emulator program.

3. Configure the terminal or terminal emulator program as follows:

❑ Baud rate: 9600 bps

❑ Data bits: 8

❑ Parity: None

❑ Stop bits: 1

❑ Flow control: None

Note
The port settings are for a DEC VT100 or ANSI terminal, or an
equivalent terminal emulator program.

When prompted for the user name and password, enter one of
the following options:

4. When prompted for the user name and password, enter one of the

following options.

❑ For Manager access, type manager as the user name. The default

password is “friend”.

❑ For Operator access, type operator as the user name. The default

password is “operator”.

Note
The user names cannot be changed and the passwords are case
sensitive. For instructions on how to change a password, refer to
Configuring the Management Passwords on page 49.
For information on the two access levels, refer to Management
Access Levels on page 32.
