AT-S25 Management Software User’s Guide
23
11. In the HypterTerminal window, hit any key to activate the ATI
Diagnostics menu.
12. In the ATI Diagnostics menu, type X to select XMODEM download
updated System Software, and press the Enter key.
The following prompt is displaying, indicating that the system is
ready for the download:
The System is now ready for download. Please
start your XMODEM transfer.
13. From the HyperTerminal main window, select the Transfer menu.
Then select Send File... from the pull-down menu, as shown in
Figure 5.
Figure 5 Local Management Window - Send File Menu
The Send File pop-up window in Figure 6 is displayed.
Figure 6 Send File Pop-Up Window
14. Click the Browse button to specify the location and the file to be
downloaded onto the switch.
15. Click on the Protocol filed and select the transfer protocol as either
Xmodem or, for faster download, 1K XModem.
The image file you are downloading is “ATS25_V200.IMG”.
16. Click Send.
