AT-S25 Management Software User’s Guide
245
The parameters are described in the table below:
6. Click Apply.
The untagged ports that you assign to the new VLAN are
automatically removed from their current VLAN assignment.
The VLAN is now ready for network operations.
PARAMETER DESCRIPTION
VID A VID value for the new VLAN.
The range of the VID value is 2 to 2048. The default will
be the next available VID number on the switch.
If this will be a unique VLAN in your network, its VID
must be unique as well.If the VLAN will be part of a
larger VLAN that spans multiple switches, its VID value
should be the same on each switch. For example, if you
are creating a VLAN called Sales that will span three
switches, you must assign the same VID value to each
Sales VLAN on the three switches.
NOTE: A VLAN must have a VID.
Name
Name of the new VLAN.
The name can be from one to 10 characters in length.
The name should reflect the function of the nodes of
the VLAN (for example, Sales or Accounting). The name
can contain spaces but not special characters, such as
asterisks (*) or exclamation points (!).
If the VLAN will be unique in your network, the name
should be unique as well. If the VLAN will be part of a
larger VLAN that spans multiple switches, the name for
the VLAN should be the same on each switch where
nodes of the VLAN are connected.
NOTE: A VLAN must be assigned a name.
Untagged Ports Ports that are in a single VLAN.
The untagged ports are from 1 to 24.
Tagged Ports Ports that associating with a VLAN that is in a multiple
VLANs.
The tagged ports are from 1 to 24.
