Section II: Local and Telnet Mangement
64
The Port Status window is displayed. Figure 18 is an example of
the window.
Figure 18 Port Status Window
The information in this window is for viewing purposes only. The
columns in the window are described in the table below:
PARAMETER DESCRIPTION
PortName/UplinkType PortName is the name of the port, and UplinkType is
the type of the applique’ in the uplink slot (AT-A14, AT-
A15, AT-A17, AT-A18, or AT-A19).
NOTE: The UplinkType only applies to the uplink ports.
State The current state of the port.
Possible settings for this parameter are:
• Enable (default)
• Disable
Nego The status of Auto-Negotiation on the port.
Possible settings for this parameter are:
• Auto - Indicates that the port is using Auto-
Negotiation to set operating speed and duplex mode.
• Manual - Indicates that the operating speed and
duplex mode have been set manually.
