AT-S25 Management Software User’s Guide
173
Displaying a List of Multicast Routers
A multicast router is a router that is receiving multicast packets from a
multicast application and transmitting the packets to host nodes. You
could use the AT-S25 software to display a list of the multicast routers
that are connected to the stack.
To display a list of the multicast routers, perform the following
procedure:
1. From the Main Menu, type 5 to select System Config Menu.
2. From the System Config Menu, type A to select Advanced
Configuration.
3. From the Advanced Configuration window, type 1 to select IGMP
Snooping Configuration.
4. From the IGMP Snooping Configuration window, type 6 to select View
Multicast Routers List.
The View Multicast Router List window in Figure 58 is displayed.
Figure 59 View Multicast Routers List Window
The information in this window is for viewing purposes only. The
columns are described in the table below:
PARAMETER DESCRIPTION
Module The module on the stack that is being used.
Port
The port on the stack where the multicast router is
connected.
VLAN The VID of the VLAN in which the port is an untagged
member.
RouterIP The IP address of the multicast router.
