C.9

Bidirectional Synchronous Disaster Recovery Example

InForm OS Version 2.3.1

Remote Copy User’s Guide

To initiate disaster recovery for a bidirectional Remote Copy pair with synchronous volume

groups:

1

On the failover system, make all secondary groups primary by reversing the direction of the

failed targets for each group. Issuing the

setrcopygroup failover

command switches

every secondary group for the specified target. For this example, this is done by reversing

the failed target InServ1 for the secondary group sync_group_1.r96 on InServ2

using the

setrcopygroup failover

command as follows:

On InServ2:

# setrcopygroup failover -t InServ1

NOTE: At this point, you can export read-write volumes from the secondary. Any

volumes already exported can now accept writes.
