-72-
4.11.4. How to check the status output
Description
z Check the status output.
Setting content ON: Close the contact.
OFF: Open the contact.
z This operation sets DO1, DO2 and DO3 to the same contact action.
z Before operation, check whether DO output testing is permitted.
For actual keying, refer to the typical operation indicated below. Set the parameter protection to OFF beforehand. (See Section 4.4.1.)
Operation
(example) Check the contact action.
Key operation Description Display
ź
Press the key 4 times to display “MAINTENANCE MODE”.
MAINTENANCE MODE
ENT
ź
Press the ENT key once to display “RAS INFORMATION”.
RAS INFORMATION
000000000000000
ź
Press the key 4 times to display “STATUS”.
DO CHECK
OFF
ENT
ź
Press the ENT key once to blink the cursor.
Note) Contact output is displayed at this time.
“OFF” is given at right.
DO CHECK
OFF
ź
Press the key once, and select “ON”.
DO CHECK
ON
Press the ENT key once to register “ON”.
DO CHECK
COMPLETE
Ļ
ENT
ź
ź
ź
ź
ʊʊʊ “ON” has been registered. ʊʊʊ
* Check the contact output “ON”.
DO CHECK
ON
ź
Press the key once, and select “OFF”.
DO CHECK
OFF
Press the ENT key once to register “OFF”.
DO CHECK
COMPLETE
Ļ
ENT
ź
ź
ź
ź
ʊʊʊ “OFF” has been registered. ʊʊʊ
* Check the contact output “OFF”.
DO CHECK
OFF
ESC
ź
Press the ESC key once to stop the cursor from blinking.
* It returns to contact output at the normal measurement status.
DO CHECK
OFF
ESC Press the ESC key once and then press the key once to enter the
measurement mode.
0.000 %
0.000 m3/h
CAUTION
Bulletin F-107-UXF3
