-71-
4.11.3. How to check the action of total pulses
Description
z Checks the action of total pulse output.
The output action can be checked upon designating the number of pulses to be outputted per second.
Settable range: 1 to 100 pulses/s (DO1/DO2 only)
Note 1) The output pulse width is as selected currently. (See 4.9.2.1.)
Set the frequency taking the pulse width into account referring to the following expression.
The number of setting pulses d 1000/(Pulse width[ms] × 2)
Example: If the pulse width is set at 50ms, select 10 pulses/s or less.
Note 2) DO1/DO2 (transistor open collector) and DO3 (relay contact) operate simultaneously.
Before checking the action, confirm whether proceeding to an action is permitted.
Note 3) DO3 (relay contact) always operates at the rate of 1 pulse/sec regardless of setting.
For actual keying, refer to the typical operation indicated below. Set the parameter protection to OFF beforehand. (See Section 4.4.1.)
Operation
(example) Perform pulse output of 5 pulses/s.
Key operation Description Display
ź
Press the key 4 times to display “MAINTENANCE MODE”.
MAINTENANCE MODE
ENT
ź
Press the ENT key once to display “RAS INFORMATION”.
RAS INFORMATION
0000000000000000
ź
Press the key 3 times to display “TOTAL PULSE”.
TOTAL PULSE
1 PULSE/s
ENT
ź
Press the ENT key once to blink the cursor.
Note) Start simulated pulse output.
TOTAL PULSE
0 01 PULSE/s
ź
Press the key twice to move the cursor.
TOTAL PULSE
00 1 PULSE/s
ź
Press the key 4 times to set “5”.
TOTAL PULSE
00 5 PULSE/s
Press the ENT key once to register.
TOTAL PULSE
COMPLETE
Ļ
ENT
ź
ź
ź
ź
ʊʊʊ 5 PULSE/s has been registered. ʊʊʊ
5 PULSE/s simulated pulse is output.
TOTAL PULSE
00 5 PULSE/s
ESC
ź
After checking the output, press the ESC key once to stop simulated
pulse output.
TOTAL PULSE
005 PULSE/s
ESC Press the ESC key once and then press the key once to enter the
measurement mode.
0.000 %
0.000 m3/h
