-28-
4.6. Checking and Setting of Piping Specifications/Detector
4.6.1. Checking piping parameter
Key operation
Description
Display
0.000 m/s
0.000 m3/h
ź
Press the
key 3 times to display “MEASURE SETUP”.
MEASURE SETUP
ENT
ź
Press the
ENT
key once to display “SYSTEM UNIT”.
SYSTEM UNIT
ENGLISH
ź
Press the
key 3 times to display “PROCESS SETTING”.
PROCESS SETTING
S= 31( 93mm)
ENT
ź
Press the
ENT
key once to display “OUTER DIAMETER”.
OUTER DIAMETER
60.00 mm
ź
Press the
key once to display “PIPE MATERIAL”.
PIPE MATERIAL
PVC
ź
Press the
key once to display “WALL THICKNESS”.
WALL THICKNESS
4.00 mm
ź
Press the
key once to display “LINING MATERIAL”.
LINING MATERIAL
NO LINING
ź
Press the
key once to display “KIND OF FLUID”.
KIND OF FLUID
WATER
ź
Press the
key once to display “VISCOSITY”.
VISCOSITY
1.003800 E-6m2/s
ź
Press the
key once to display “SENSOR MOUNT”.
SENSOR MOUNT
V METHOD
ź
Press the
key once to display “SENSOR TYPE”.
SENSOR TYPE
SX1-A
ź
Press the
key once to display “TRANS. VOLTAGE”.
TRANS. VOLTAGE
80 Vpp
ESC
Press the
ESC
key twice, and press the
key twice to return to the
measurement mode.
0.000 m/s
0.000 m3/h
Bulletin F-107-UXF3
