-70-
4.11.2. How to set the constant current output
Description
z Generates a fixed value output of analog signal.
Application example: The operation of a connected receiver is checked by generating a fixed value output of analog signal.
z In the constant current setting mode (OUTPUT SETTING), set the constant current output value.
Settable range: -20%(0.8mA) to +120%(23.2mA)
For actual keying, refer to the typical operation indicated below. Set the parameter protection to OFF beforehand. (See Section 4.4.1.)
Operation
(example) Set the constant current output of 50% (12mA).
Key operation Description Display
ź
Press the key 4 times to display “MAINTENANCE MODE”.
MAINTENANCE MODE
ENT
ź
Press the ENT key once to display “RAS INFORMATION”.
RAS INFORMATION
0000000000000000
ź
Press the key twice to display “OUTPUT SETTING”.
CURRENT
OUTPUT SETTING
ENT
ź
Press the ENT key once to display the setting screen.
OUTPUT SETTING
0 %
ENT
ź
Press the ENT key once to blink the cursor.
Note) Start constant current output.
OUTPUT SETTING
+ 000 %
ź
Enter “5” by the and the key.
OUTPUT SETTING
+0 5 0 %
Press the ENT key once to output 12mA.
OUTPUT SETTING
COMPLETE
Ļ
ENT
ź
ź
ź
ź
ʊʊʊ Outputting 12mA. ʊʊʊ OUTPUT SETTING
50 %
ESC
ź
Press the ESC key once to stop constant current output.
Note) Current output is in the measurement status.
CURRENT
OUTPUT SETTING
ESC Press the ESC key once and then press the key once to enter the
measurement mode.
0.000 %
0.000 m3/h
