(2) Setting method when sensor type is SX1-A, SX1-B, SX1-C, SX2-A, SX2-B
Operation
(example)
Carry out setting for measuring the flow rate of water flowing through PVC pipe (for tap water) having 100 mm of
nominal diameter, using SX2-A detector.
Key operation
Description
Display
ź
Press the
key 3 times to display “MEASURE SETUP”.
MEASURE SETUP
ENT
ź
Press the
ENT
key once to display “SYSTEM UNIT”.
SYSTEM UNIT
METRIC
ź
Press the
key 3 times to display “PROCESS SETTING”.
PROCESS SETTING
S= 31 ( 93mm)
ENT
ź
Press the
ENT
key once to display “OUTER DIAMETER”.
OUTER DIAMETER
114.00 mm
ź
Press the
key 7 times to blink the cursor.
SENSOR TYPE
SX1-A
ENT
ź
Press the
ENT
key once to blink the cursor.
SENSOR TYPE
SX1-A
ź
Press the
key multiple times to display “SX2-A” on the 2nd line.
SENSOR TYPE
SX2-A
Press the
ENT
key once to register “SX2-A”.
SENSOR TYPE
COMPLETE
Ļ
ENT
ź
ź
ź
ź
ʊʊʊ “SX2-A” has been registered. ʊʊʊ
SENSOR TYPE
SX2-A
ESC
ź
Press the
ESC
key once to display “PROCESS SETTING”.
“S=76.30mm” is displayed on the 2nd line.
Align the sensor mounting spacing to 76.3mm, and attach the sensor to
the pipe.
PROCESS SETTING
S= 76.30mm
ESC
Press the
ESC
key once and the
key twice to return to the
measurement mode.
0.000 m3/h
0.000 m3
