4.9.2.3. TOTAL mode (total reset, start, stop)
Description
z The total is started, stopped or reset.
z Settable range: START, STOP, TOTAL RESET
START : Starts totalizing. Totalizes continuously from the stopped status.
STOP : Stops totalizing. Setting cannot be changed when it is not stopped.
RESET : Resets the total memory to the preset value, and starts totalizing.
A resetting action simultaneously resets both forward total memory and reverse total memory.
For actual keying, refer to the typical operation indicated below. Set the parameter protection to OFF beforehand. (See Section 4.4.1.)
Operation
(example) Reset the total value (preset value 0m 3 ), and restart a total.
Key operation Description Display
0.00 m3/h
+ 127.26 m3
ź
Press the key twice to display “OUTPUT SETTING”.
OUTPUT SETTING
ENT
ź
Press the ENT key once to display “ZERO ADJUSTMENT”.
ZERO ADJUSTMENT
SET ZERO
ź
Press the key 5 times to display “TOTAL”.
TOTAL
ENT
ź
Press the ENT key once to display “TOTAL MODE”.
TOTAL MODE
START
ENT
ź
Press the ENT key once to blink the cursor.
TOTAL MODE
START
ź
Press the key twice to display “TOTAL RESET”.
TOTAL MODE
TOTAL PRESET
Press the ENT key twice to execute “TOTAL RESET”.
TOTAL MODE
COMPLETE
Ļ
ENT
ź
ź
ź
ź
ʊʊʊ The total operation is started. ʊʊʊ TOTAL MODE
TOTAL PRESET
ESC Press the ESC key twice and then press the key 3 times to enter
the measurement mode.
0.00 m3/h
0.00 m3
