4.3. Parameter initial value list
Factory-set value is shown below. (When parameter setting is not provided.)
Setting unit Setting range Initial value Setting value
1 Parameter protection No. of menu: 2 PROTECTION ON PROTECTION ON, PROTECTION OFF
2 ID No 0000 to 9999 0000 ID No. is invalid when 0000 is selected.
3 Language No. of menu: 5 English *1 English, Japanese, German, French and
Spanish
4 System unit No. of menu: 2 Metric Metric or inch
5 Flow unit No. of menu: 18 ft 3 /s gal/s, gal/min, gal/h, gal/d, kgal/d, Mgal/d, ft 3 /s,
ft 3 /s, ft 3 /min, ft 3 /d, kft 3 /d, kft /d, BBL/s, BBL/min,
BBL/h, BBL/d, kBBL/d, MBBL/d
6 Total unit No. of menu: 8 m 3 gal, kgal, ft 3 , kft 3 , Mft 3 , BBL, kBBL, Acre-ft
7 Outer diameter 6.00 to 6200.00mm 60.00mm [mm, in]
8 Pipe material No. of menu: 13
Sound velocity: 1000 to
3700m/s PVC pipe Carbon steel, stainless steel, PVC, Copper,
Cast iron, Aluminum, FRP, Ductile iron, PEEK,
PVDF, Acrylic, and PP
Pipe sound velocity
(Sound velocity: [m/s, ft/s])
9 Wall thickness 0.10 to 100.00mm 4.00mm [mm, in]
10 Lining material No. of menu: 8
Sound velocity: 1000 to
3700m/s No lining No lining, Tar epoxy, Mortar, Rubber, TFE,
Glass, PVC
Lining S.V. (Sound velocity: [m/s, ft/s])
11 Lining thickness 0.01 to 100.00mm – [mm, in]
12 Kind of fluid No. of menu: 18
Sound velocity: 300 to
2500m/s Water Seawater, dist. water, ammonia, alcohol,
benzene, bromide, ethanol, glycol, kerosene,
milk, methanol, toluol, lube oil, fuel oil, petrol
and refrigerant R410
Fluid S.V. (Sound velocity: [m/s, ft/s])
13 Dynamic viscosity
coefficient
0.001 to 999.999
×10
-6 m 2 /s
1.0038
×10
-6 m 2 /s
[×10 -6 m 2 /s, ft 2 /s]
14 Sensor mounting method No. of menu: 2 V method V method, Z method
15 Sensor type No. of menu: 10 – SX1-A, SX1-B, SX1-C, SX2-A, SX2-B,
Reserved (for future use)
16
Measuring condition
Transmission voltage No. of menu: 4 80Vpp 20Vpp, 40Vpp, 80Vpp, 160Vpp
17 Zero adjustment No. of menu: 2 Clear (unadjusted) Clear, adjustment (Clear has been factory-set.)
18 Damping 0.0 to 100.0sec 5.0sec sec
19 Low flow cut 0 to 5m/s in terms of
flow velocity 0.150m 3 /h [(5) unit]
20 Content of display 1st
line No. of menu: 7 Flow velocity (m/s) Flow velocity, Flow rate, Flow rate (%), +Total
(Actual), +Total pulse, -Total (Actual) and -Total
pulse
21 Decimal point position
of display 1st line
.
††††††††
(Fill in the specified digit)
22 Content of display 2nd
line No. of menu: 7 Flow rate (m/s) Flow velocity, Flow rate, Flow rate (%), +Total
(Actual), +Total pulse, -Total (Actual) and -Total
pulse
23
Display
Decimal point position
of display 2nd line
.
††††††††
(Fill in the specified digit)
24 Range type No. of menu: 4 Single range Single range, Auto 2 range, Bi-dir range and
Bi-dir Auto 2 range
25 Full scale 1 0, ±0.3 to ±32m/s in
terms of flow velocity 15.000m 3 /h [(5) unit]
26 Full scale 2 0, ±0.3 to ±32m/s in
terms of flow velocity 0.000m 3 /h [(5) unit]
27 Hysteresis 0.00 to 20.00 10.00% %
28 Burnout (current) No. of menu: 5 Hold Not used, Hold, Lower, Upper and Zero
29 Burnout timer 0 to 900sec 10sec sec
30 Output limit low -20 to 0% -20% %
31 Output limit high 100 to 120% 120% %
32 Rate limit 0 to 5m/s in terms of
flow velocity 0.000m 3 /h [(5) unit]
33
Analog output
Rate limit timer 0 to 900sec 0sec sec
34 Total mode No. of menu: 3 Stop Start, Stop and Reset
35 Pulse value 0.000000 to 99999999 0m 3 [(6) unit]
36 Total preset 0.000000 to 99999999 0m 3 [(6) unit]
37 Pulse width No. of menu: 5 50.0msec 5.0msec, 10.0msec, 50.0msec, 100.0msec,
200.0msec
38 Burnout (total) No. of menu: 2 Hold Not used, hold
39
Output condition
T
o
ta
l output
Burnout timer 0 to 900sec 10sec sec
