PVDF-HP
SDR33
S16 PN10
SDR21
S10 PN16
SDR17
S8 PN20
Outer
diameter
(mm)
Thickness
(mm)
Thickness
(mm)
Thickness
(mm)
16 1.5 1.5
20 1.9 1.9
25 1.9 1.9
32 2.4 2.4
40 2.4 2.4
50 3.0 3.0
63 2.5 3.0
75 2.5 3.6
90 2.8 4.3
110 3.4 5.3
125 3.9 6.0
140 4.3 6.7
160 4.9 7.7
180 5.5 8.6
200 6.2 9.6
225 6.9 10.8
250 7.7 11.9
280 8.6 13.4
315 9.7 15.0
355 10.8
400 12.2
450 13.7
Heat-resistant hard vinyl chloride pipe PVC-C
(JIS G6776-2004). Unit:mm except as noted
Nominal
diameter
Outer
diameter
(mm)
Thickness
(mm)
Weight
(kg/m)
13 18.0 2.5 0.180
16 22.0 3.0 0.265
20 26.0 3.0 0.321
25 32.0 3.5 0.464
30 38.0 3.5 0.561
40 48.0 4.0 0.818
50 60.0 4.5 1.161
Polyethylene pipe for city water service
(Japan Polyethylene Pipes Association for Water Service standard PTC K 03:2006). Unit: mm except as noted
Nominal diameter
Outer diameter
(mm)
Thickness
(mm)
Inner diameter
(mm)
Weight
(kg/m)
50 63.0 5.8 50.7 1.074
75 90.0 8.2 72.6 2.174
100 125.0 11.4 100.8 4.196
150 180.0 16.4 145.3 8.671
200 250.0 22.7 201.9
16.688
