- 25 -
Setting unit Setting range Initial value Setting value
40 DO1 output type No. of output content
menu: 10
No. of alarm menu: 3
Flow switch range
0 to 32m/s in terms of
flow velocity
Total switch range
0.000000 to 99999999 Not used †Not used
†+Total pulse
†-Total pulse
†Range full scale 2
†Alarm [All, Device error, Process error]
†Flow rate switch
†Flow SW high [(5) unit]
†Flow SW low [(5) unit]
†Total switch [(6) unit]
†Range over
†Pulse range over
†–Flow direction
41 DO1 Output operation No. of menu: 2 Active ON Active ON, Active OFF
42 DO2 Output type No. of output content
menu: 10
No. of alarm menu: 3
Flow switch range
0 to 32m/s in terms of
flow velocity
Total switch range
0.000000 to 99999999 Not used †Not used
†+Total pulse
†-Total pulse
†Range full scale 2
†Alarm [All, Device error, Process error]
†Flow rate switch
†Flow SW high [(5) unit]
†Flow SW low [(5) unit]
†Total switch [(6) unit]
†Range over
†Pulse range over
†–Flow direction
43 DO2 Output operation No. of menu: 2 Active ON Active ON, Active OFF
44 DO3 Output type No. of output content
menu: 10
No. of alarm menu: 3
Flow switch range
0 to 32m/s in terms of
flow velocity
Total switch range
0.000000 to 99999999 Not used †Not used
†+Total pulse
†-Total pulse
†Range full scale 2
†Alarm [All, Device error, Process error]
†Flow rate switch
†Flow SW high [(5) unit]
†Flow SW low [(5) unit]
†Total switch [(6) unit]
†Range over
†Pulse range over
†–Flow direction
45 DO3 Output operation No. of menu: 2 Active ON Active ON, Active OFF
46 DI1 Input type No. of input content
menu: 3 Not used †Not used
†Total reset
†Zero adjustment
47 DI1 Input operation No. of menu: 2 Active ON Active ON, Active OFF
48 Zero calibration -5 to 5m/s in terms of
flow velocity 0.000m 3 /h [(5) unit]
49 Span calibration -200.00 to 200.00% 100.00% %
50
Output condition
Operation mode No. of menu: 2 Standard Standard, High speed
51 Communication mode No. of menu: 2 RS-232C RS-232C, RS-485
52 Baud rate No. of menu: 3 9600bps 9600bps, 19200bps, 38400bps
53 Parity No. of menu: 3 Odd None, Odd, Even
54 Stop bit No. of menu: 2 1 bit 1 bit, 2 bits
55 Station No. 1 to 31 1 (In case of RS-485)
56 Communication Communication protocol No. of menu: 2 MODBUS MODBUS, Other
Bulletin F-107-UXF3
