1.2.4. Small/middle size detector (SX1-A, SX1-B)
SX1-A SX1-B
No. Name
Description
(1)
Signal cable
Transmits send/receive signals.
(2)
Detector
Sends and receives an ultrasonic wave.
(3)
Chain
Fastens the detector on pipe.
(4)
Wire rope
Fastens the detector on pipe.
(5)
Mounting spring
Removes the play of wire rope.
(3)
(2)
(1)
(5)
(1)
(4)
(2)
Bulletin F-107-UXF3
1.2.3. Reserved
1.2.2. Reserved
