4.8.3. How to set the total unit
Description
z Select the unit of total volume.
z Metric system
Total unit ········· mL, L, m
3
(factory set), km
3
, Mm
3
, mBBL, BBL, kBBL, gal, kgal, ft , kft , Mft , Acre-ft
When setting, stop status should be set at total mode. (See Section 4.9.2.)
For actual keying, refer to the typical operation indicated below. Set the parameter protection to OFF beforehand. (See Section 4.4.1.)
Operation
(example)
Set a flow rate unit to “L”.
Key operation
Description
Display
ź
Press the
key
㧟imes to display ̌MEASURE SETUP̍.
MEASURE SETUP
ENT
ź
Press the
ENT
key once to display “SYSTEM UNIT”.
SYSTEM UNIT
METRIC
ź
Press the
key once to display “TOTAL UNIT”.
TOTAL UNIT
m3
ENT
ź
Press the
ENT
key once to blink the cursor.
TOTAL UNIT
m3
ź
Press the
key twice to display “L”.
TOTAL UNIT
L
Press the
ENT
key once to register.
TOTAL UNIT
COMPLETE
Ļ
ENT
ź
ź
ź
ź
ʊʊʊ “L” has been registered. ʊʊʊ
TOTAL UNIT
L
ESC
Press the
ESC
key once and the
key twice to return to the
measurement mode.
0.000 L
0.000 L/min
