-124-
7.2. Piping data
Stainless steel pipe for pipe arrangement (JIS G3459-2004). Nominal diameters A & B represent nominal sizes in mm & inches.
Thickness
Nominal
diameter
Schedule
5S
Schedule
10S
Schedule
20S
Schedule
40
Schedule
80
Schedule
120
Schedule
160
A B
Outer
diameter
mm
Thickness
mm
Thickness
mm
Thickness
mm
Thickness
mm
Thickness
mm
Thickness
mm
Thickness
mm
15
1/2
21.7
1.65 2.1 2.5 2.8 3.7 - 4.7
20
3/4
27.2
1.65 2.1 2.5 2.9 3.9 - 5.5
25
1
34.0
1.65 2.8 3.0 3.4 4.5 - 6.4
32
1
1/4
42.7
1.65 2.8 3.0 3.6 4.9 - 6.4
40
1
1/2
48.6
1.65 2.8 3.0 3.7 5.1 - 7.1
50
2
60.5
1.65 2.8 3.5 3.9 5.5 - 8.7
65
2
1/2
76.3
2.1 3.0 3.5 5.2 7.0 - 9.5
80
3
89.1
2.1 3.0 4.0 5.5 7.6 - 11.1
90
3
1/2
101.6
2.1 3.0 4.0 5.7 8.1 - 12.7
100
4
114.3
2.1 3.0 4.0 6.0 8.6 11.1
13.5
125
5
139.8
2.8 3.4 5.0 6.6 9.5 12.7
15.9
150
6
165.2
2.8 3.4 5.0 7.1 11.0
14.3
18.2
200
8
216.3
2.8 4.0 6.5 8.2 12.7
18.2
23.0
250
10
267.4
3.4 4.0 6.5 9.3 15.1
21.4
28.6
300
12
318.5
4.0 4.5 6.5 10.3 17.4 25.4 33.3
350
14
355.6
- - -
11.1
19.0
27.8
35.7
400
16
406.4
-
-
- 12.7 21.4 30.9 40.5
450
18
457.2
-
-
- 14.3 23.8 34.9 45.2
500
20
508.0
-
-
- 15.1 26.2 38.1 50.0
550
22
558.8
-
-
- 15.9 28.6 41.3 54.0
600
24
609.6
-
-
- 17.5 34.0 46.0 59.5
650
26
660.4
-
-
- 18.9 34.0 49.1 64.2
Polyethylene pipe for city water (JIS K6762-2004)
1st type (Soft pipe)
2nd type (Hard pipe)
Nominal
diameter
(mm)
Outer
diameter
(mm)
Thickness
(mm)
Weight
(kg/m)
Thickness
(mm)
Weight
(kg/m)
13 21.5 3.5 0.184 2.5 0.143
20 27.0 4.0 0.269 3.0 0.217
25 34.0 5.0 0.423 3.5 0.322
30 42.0 5.5 0.595 4.0 0.458
40 48.0 6.5 0.788 4.5 0.590
50 60.0 8.0 1.210 5.0 0.829
Galvanized steel pipe for city water SGPW (JIS G3442-2004). Nominal diameters A & B represent nominal sizes in mm & inches.
Nominal diameters
(A) (B)
Outer diameter
(mm)
Thickness
(mm)
15 1/2 21.7 2.8
20 3/4 27.2 2.8
25 1 34.0
3.2
32 1
1/4 42.7 3.5
40 1
1/2 48.6 3.5
50 2 60.5
3.8
65 2
1/2 76.3 4.2
80 3 89.1
4.2
90 3
1/2
101.6 4.2
100 4 114.3
4.5
125 5 139.8
4.5
150 6 165.2
5.0
200 8 216.3
5.8
250 10 267.4
6.6
300 12 318.5
6.9
Bulletin F-107-UXF3
