-125-
Asbestos cement pipe for city water (JIS A5301-1971)
1st type 2nd type 3rd type 4th type
Nominal
diameter
(mm)
Thickness
of
connected
part
(mm)
Outer
diameter of
connected
part
(mm)
Thickness
of
connected
part
(mm)
Outer
diameter of
connected
part
(mm)
Thickness
of
connected
part
(mm)
Outer
diameter of
connected
part
(mm)
Thickness
of
connected
part
(mm)
Outer
diameter of
connected
part
(mm)
50 10 70 - - - - - -
75 10 95 - - - - - -
100 12 124 10 120 9 118 - -
125 14 153 11 147 9.5 144 - -
150 16 182 12 174 10 170 - -
200 21 242 15 230 13 226 11 222
250 23 296 19 288 15.5 281 12 274
300 26 352 22 344 18 336 14 328
350 30 410 25 400 20.5 391 16 382
400 35 470 29 458 23 446 18 436
450 39 528 32 514 26 502 20 490
500 43 586 35 570 28.5 557 22 544
600 52 704 42 684 34 668 26 652
700 - - 49 798 39 778 30 760
800 - - 56 912 44 888 34 868
900 - - - - 49 998 38 976
1000 - - - - 54 1108 42 1084
1100 - - - - 59 1218 46 1192
1200 - - - - 65 1330 50 1300
1300 - - - - 73 1496 57 1464
1500 - - - - 81 1662 63 1626
Polyethylene pipe for general use (JIS K6761-2004)
1st type
(Soft pipe)
2nd type
(Hard pipe) Nominal
diameter
Outer
diameter
(mm)
Thickness
(mm)
Thickness
(mm)
13 21.5 2.7 2.4
20 27.0 3.0 2.4
25 34.0 3.0 2.6
30 42.0 3.5 2.8
40 48.0 3.5 3.0
50 60.0 4.0 3.5
65 76.0 5.0 4.0
75 89.0 5.5 5.0
100 114 6.0 5.5
125 140 6.5 6.5
150 165 7.0 7.0
200 216 - 8.0
250 267 - 9.0
300 318 - 10.0
Hi vinyl chloride pipe (city water pipe size - unit mm)
Nominal
diameter
Outer
diameter
Pipe
thickness
13 18.0 2.5
20 26.0 3.0
25 32.0 3.5
30 38.0 3.5
40 48.0 4.0
50 60.0 4.5
75 89.0 5.8
100 114.0 7.0
125 140.0 7.5
150 165.0 8.5
Hi vinyl chloride pipe (conduit size - unit mm)
Nominal
diameter of
pipe
Outer
diameter
Pipe
thickness
28 34.0 3.0
35 42.0 3.5
41 48.0 3.5
52 60.0 4.0
65 76.0 4.5
78 89.0 5.5
Vertical type cast iron pipe (JIS G5521 - unit mm)
Pipe thickness
T Nominal
diameter
D
Normal
pressure
pipe
Low
pressure
pipe
Actual
outer
diameter
D1
75 9.0 - 93.0
100 9.0 - 118.0
150 9.5 9.0 169.0
200 10.0 9.4 220.0
250 10.8 9.8 271.6
300 11.4 10.2 322.8
350 12.0 10.6 374.0
400 12.8 11.0 425.6
450 13.4 11.5 476.8
500 14.0 12.0 528.0
600 15.4 13.0 630.8
700 16.5 13.8 733.0
800 18.0 14.8 836.0
900 19.5 15.5 939.0
1000 22.0 - 1041.0
1100 23.5 - 1144.0
1200 25.0 - 1246.0
1350 27.5 - 1400.0
1500 30.0 - 1554.0
Bulletin F-107-UXF3
(unit:mm)
