Chapter 11 Bridge
MES-2110 User’s Guide
96
Edge Select On when the port is connected to an end node (a computer
network card for example).
Select Off when the port is connected to a bridge node.
P2P Select On when the port is connected to one bridge as a Point-to-
Point link type.
Select Off when the port is connected to multiple bridges as a
Shared Medium link type.
Select Auto to have the MES-2110 automatically determine the
link type.
Undo Click this to restore your last saved settings.
Apply Click Apply to save your changes to the MES-2110’s run-time
memory. The MES-2110 loses these changes if it is turned off or
loses power, so use the Save Settings link in the navigation
panel to save your changes to the non-volatile memory when you
are done configuring.
Port This indicates the port index number.
Type This indicates the cable type connected to the port.
Priority (1~255) This indicates the port priority.
Cost (1~65535) This indicates the path cost for the port.
Edge This indicates whether the port is connected to an end node (On)
or a bridge node (Off).
P2P This indicates whether the port is connected to one bridge (On),
multiple bridges (Off), or if the connection type is determined
automatically (Auto).
Port Status This indicates whether the port is Forwarding or Blocking frame
transmission.
Port Role This indicates the port behavior as a Disabled, Alternate,
Backup, Root, Designated or NonStp port.
Table 27 Configuration > Bridge Menu > RSTP Per Port Config
LABEL DESCRIPTION
