Chapter 23 Command Line Interface

MES-2110 User’s Guide

196

23.8.1 MVR Command Example

This example configures MVR in the following ways:

1

Enters MVR mode. This creates a multicast VLAN with the name StreamVlan and
the multicast VLAN ID of 100.

2

Specifies source port 9 for the multicast group.

3

Specifies receiver ports 1-4 and 10 for the multicast group.

4

Specifies dynamic mode for the multicast group.

5

Sets the ports 9 and 10 to tag VLAN IDs.

6

Configures MVR multicast group addresses 227.3.3.1 through 227.3.3.10 for
multicast group ID 1.

mode

Sets the MVR mode to dynamic or compatible for
the current MVR group.

name

Sets the current MVR group name for
identification purposes.

name

: Enter 1-30 characters.

query-mode

Sets the query mode of the current MVR group.

receiver-port

Sets the receiver port(s) for the current MVR
group. An MVR receiver port can only receive
multicast traffic in a multicast VLAN.

source-port

Sets the source port(s) for the current MVR
group. An MVR source port can send and receive
multicast traffic in a multicast VLAN.

tagged

Sets the port(s) to VLAN tags for the current
MVR group.

Table 81 MVR-Configuration Mode Commands

COMMAND

DESCRIPTION

MES-2110(config)# mvr 100

MES-2110(config-mvr)# no inactive

MES-2110(config-mvr)# name StreamVlan

MES-2110(config-mvr)# mode dynamic

MES-2110(config-mvr)# receiver-port 1,2,3,4,10

MES-2110(config-mvr)# source-port 9

MES-2110(config-mvr)# tagged 9,10

MES-2110(config-mvr)# group 1 227.3.3.1 10
