Chapter 12 VLAN
MES-2110 User’s Guide
109
12.5.9 The Management VLAN Screen
Use this to configure the management VLAN. A port must belong to the
management VLAN if you want to access the MES-2110’s web configurator via that
Pri-Override Select Enable to ignore the priority level assigned to the
transmitted frames. Otherwise, select Disable.
Port This shows ports 1 to 10.
Member This shows the VLAN group setting for the port, whether it is a
Member, Untagging, Tagging or Non-member.
Undo Click this to reset the values in this screen to their last-saved
values.
Apply Click Apply to save your changes to the MES-2110’s run-time
memory. The MES-2110 loses these changes if it is turned off or
loses power, so use the Save Settings link in the navigation
panel to save your changes to the non-volatile memory when you
are done configuring.
Tag VLAN Status (M:member U:untag T:tag)
Add VLAN Configuration
VLAN ID
Enter a VLAN ID number from 1 to 4094.
Priority This is the priority you want to assign to the Tag-based VLAN.
Pri-Override Select Enable to ignore the priority level assigned to the
transmitted frames. Otherwise, select Disable.
Port 1-10 A Member port is a permanent member of this VLAN group.
An Untagging port strips off the 802.1Q tag from incoming and
outgoing frames. Use this to send untag frames to devices that do
no support the 802.1Q feature.
A Tagging port tags incoming and outgoing frames with this
VLAN group information.
A Non-member port does not participate in the VLAN group.
Page Up Click this to view the next page.
Page Down Click this to view the previous page.
Refresh Click this to refresh the screen.
Page... Set Enter a page number and click Set to go to that page.
Table 36 Configuration > VLAN Menu > Tag-Based > Tag-Based info.
LABEL DESCRIPTION
