Page 29
MES-2110 User’s Guide
29
C
H A P T E R
3
Hardware Overview
This chapter describes the front panel and rear panel of the MES-2110 and shows
you how to make the hardware connections.
3.1 Front Panel
The following figure shows the front panel of the MES-2110.
Figure 9 Front Panel
Ethernet
Ports
Dual Personality
Interfaces
Console Port
LEDs
DC Terminal
Block Header
Mini-GBIC slots
AC Power Connection
