Chapter 21 QoS
MES-2110 User’s Guide
159
Port
This label shows the port you are configuring.
Priority Mode
Select a priority mode for the port.
802.1p Priority uses port priority as queuing basis. Assign a
priority level to each port in the 802.1p Priority screen (
Tag Priority uses VLAN tag priority as queuing basis. See
for more details on configuring tag
priority.
IP ToS Priority uses IP DSCP priority as queuing basis. See
for more details on configuring IP DSCP
priority.
IP & Tag Priority uses both IP DSCP priority and tag priority as
queuing basis.
IP Over Tag
Use this to enable or disable IP Over Tag on the port.
When you enable this feature and the MES-2110 receives a frame
containing both IP DSCP and tag priority information, the MES-
2110 will only use the IP DSCP priority information.
All Port
Use this to set the priority mode for all ports.
Undo
Click this to load your last saved settings.
Apply
Click Apply to save your changes to the ZyXEL Device’s run-time
memory. The ZyXEL Device loses these changes if it is turned off
or loses power, so use the Save Settings link in the navigation
panel to save your changes to the non-volatile memory.
QoS Base Status
Port1-10
This is the port number.
Schedule
This is the schedule mode used on the MES-2110.
Priority Mode
This is the priority mode used on the port.
IP Over Tag
This shows whether the IP over tag feature is enabled or disabled
on the MES-2110.
Table 60 Configuration > QoS Menu > Base Configuration
LABEL
DESCRIPTION
