Chapter 14 Broadcast Storm Control
MES-2110 User’s Guide
114
The following table describes the labels in this screen.
Table 39 Configuration > Storm Control
LABEL DESCRIPTION
Storm Control Configuration
Port Number
Use this to select a port number.
Mode Select the Broadcast, Multicast or DLF mode from the list.
Rate Level Select a rate range from the list. Options are: 64K~960K (64+),
1M~100M (1M+), 110M~1000M (10M+).
Rate Limit Specify specify how many frames the port receives per second. The unit
changes depending on how you configure in the Rate Level field. The
value you enter in this field must be within the rate level range.
Active Use this to enable or disable storm control.
Undo Click this to restore your last saved settings.
Apply Click Apply to save your changes to the MES-2110’s run-time memory.
The MES-2110 loses these changes if it is turned off or loses power, so
use the Save Settings link in the navigation panel to save your changes
to the non-volatile memory when you are done configuring.
Storm Control Status
Port
This is the port number.
Broadcast
Limit This is the broadcast frame limit on the port.
Active This shows whether broadcast control is enabled or disabled on the port.
Multicast Limit This is the multicast frame limit on the port.
Active
This shows whether multicast control is enabled or disabled on the port.
DLF Limit This is the Destination Lookup Failure (DLF) frame limit on the port.
Active This shows whether DLF control is enabled or disabled on the port.
