Chapter 13 Bandwidth Control

MES-2110 User’s Guide

112

The following table describes the related labels in this screen.

Table 38 Configuration > Bandwidth Control

LABEL

DESCRIPTION

Bandwidth Control Configuration
Port Number Use this to select a port number.
Mode

This shows the Ingress (incoming) or Egress (outgoing) mode.

Rate Level

Select a rate range from the list. Options are: 64K~960K (64+), 1M~100M
(1M+), 110M~1000M (10M+).

Rate Limit

Specify the maximum bandwidth allowed for the traffic flow on a port. The
unit changes depending on how you configure in the Rate Level field. The
value you enter in this field must be within the rate level range.

Active

Use this to enable or disable bandwidth control.

Undo

Click this to restore your last saved settings.

Apply

Click Apply to save your changes to the MES-2110’s run-time memory.
The MES-2110 loses these changes if it is turned off or loses power, so use
the Save Settings link in the navigation panel to save your changes to the
non-volatile memory when you are done configuring.

Bandwidth Control Status
Port

This is the port number.

Ingress Limit This is the ingress rate limit on the port.
Active

This shows whether bandwidth control for ingress traffic is enabled or
disabled on the port.

Egress Limit

This is the egress rate limit on the port.

Active

This shows whether bandwidth control for egress traffic is enabled or
disabled on the port.
