ZyXEL Communications MES-2110 User Manual
Page 116

Chapter 15 Port Mirroring
MES-2110 User’s Guide
116
The following table describes the labels in this screen.
Table 40 Configuration > Port Mirroring
LABEL
DESCRIPTION
Mirroring
Mode
Use this to enable or disable the port mirroring feature. The active port
mirroring feature monitors both incoming and outgoing traffic.
Monitoring
Port
The monitoring port is the port you copy the traffic to in order to examine it
in more detail without interfering with the traffic flow on the original port(s).
Select the monitor port number from the list.
Monitored
Port
Select the port(s) to mirror the traffic on a port.
Undo
Click this to restore your last saved settings.
Apply
Click Apply to save your changes to the MES-2110’s run-time memory. The
MES-2110 loses these changes if it is turned off or loses power, so use the
Save Settings link in the navigation panel to save your changes to the non-
volatile memory when you are done configuring.
