Chapter 12 VLAN
MES-2110 User’s Guide
107
12.5.7 The Tag-Based Port Information Screen
Use this screen to configure how the MES-2110 handles incoming traffic passing
through the port.
Click Configuration > VLAN Menu > Tag-Based > Port Info. to open the
following screen.
Figure 43 Configuration > VLAN Menu > Tag-Based > Port Info.
The following table describes the labels in this screen.
Table 35 Configuration > VLAN Menu > Tag-Based > Port Info.
LABEL DESCRIPTION
Port This is the port index number.
PVID Enter a number between 1 and 4094 as the port VLAN ID.
Ingress Filter Use this to determine the action about incoming traffic passing
through the port.
• NonMember: Forward, Untagged: Forward: Forward
frames that do not belong to any VLAN group and forward
untagged VLAN frames.
• NonMember: Drop, Untagged: Forward: Drop frames that
do not belong to any VLAN group and forward untagged VLAN
frames.
• NonMember: Drop, Untagged: Drop: Drop frames that do
not belong to any VLAN group and drop untagged VLAN
frames.
Isolation Use this to enable or disable port isolation.
Port isolation allows each port to communicate only with the
management port but not communicate with each other. This
option is the most limiting but also the most secure.
