Chapter 20 MAC

MES-2110 User’s Guide

155

The following table describes the labels in this screen.

Table 58 Configuration > MAC Menu > MAC Filter Config

LABEL

DESCRIPTION

MAC Filter Configuration
Status

Use this to determine whether to allow or deny traffic transmitted
from the source MAC address.

Port

Select the port through which traffic from the source MAC address
is transmitted.

Priority

Select a priority level from 0 to 7.

Pri-Override

Use this to ignore the priority level assigned to the transmitted
frames.

MAC Address

Type a MAC address in valid MAC address format, that is, six
hexadecimal character pairs.

Apply

Click Apply to save your changes to the ZyXEL Device’s run-time
memory. The ZyXEL Device loses these changes if it is turned off
or loses power, so use the Save Settings link in the navigation
panel to save your changes to the non-volatile memory.

Allowed Table
Port

This is the port number through which traffic from the source MAC
address is transmitted.

MAC Address

This is the source MAC address.

Priority

This shows the priority level.

Pri-Override

This shows whether priority level override is enabled or disabled.

Delete

Click this to remove the rule.

Page Up/Down

Click this to view the previous or next page.

Denied Table
Apply

Click Apply to save your changes to the ZyXEL Device’s run-time
memory. The ZyXEL Device loses these changes if it is turned off
or loses power, so use the Save Settings link in the navigation
panel to save your changes to the non-volatile memory.

MAC Address

This is the source MAC address.

Delete

Click this to remove the rule.

Page Up/Down

Click this to view the previous or next page.
