Chapter 10 802.1x
MES-2110 User’s Guide
83
10.5 802.1x Radius Server Configuration Screen
Use this screen to view a summary of port authentication settings on the MES-
2110 and in each individual ports.
Click Configuration > 802.1x > 802.1x Status in the navigation panel to
display the screen as shown.
Figure 35 Configuration > 802.1x Status
The following table describes the labels in this screen.
Table 18 Configuration > 802.1x Status
LABEL DESCRIPTION
802.1x This shows if port authentication is enabled on the MES-2110.
Guest VLAN This shows if a Guest VLAN is enabled on the Switch.
Reauth-Max This shows the number of times the MES-2110 attempts to authenticate
clients for port access.
Server IP
Address This is the IP address of the RADIUS server.
Server
Shared Key This is the password shared between the external authentication server
and the MES-2110.
Server UDP
Port Number This is the port number of the RADIUS server.
Server
Accounting
Port Number This is the port number of the external accounting server.
Server Time-
Out This shows how many minutes a session can be idle before the session
times out.
When a session times out, the client has to send a new request to the
server and be authenticated again.
The table below describes the settings for ports 1-10
Active
This shows if port authentication is enabled on the port.
